A. Schild 1126
(AS, A Schild)
Ligne: 13.5'''
Jewels: 1/5/14/17
Power Reserve: 39 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1975
Diameter: 30.46 mm
Height: 5.5 mm
Hands: 1.50 x 0.90 x 0.22 mm
The A. Schild 1126 watch movement features a pin-lever escapement and utilizes an indirect minute hand friction clutch on the barrel. This movement is manually wound and includes functions such as sweep second and date. It was commonly used during the approximate period of 1975.
The A. Schild 1126 features the following functions:
- Date
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.15 x 0.120 x 320 x 10.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
