A Michel 396
Ligne: 11.5'''
Jewels: 17
Power Reserve: 42 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: 1972-
Diameter: 26 mm
Height: 3.8 mm
Hands: 1.50 x 0.90 x 0.21 mm
Base: International Durowe 7421
The A Michel 396 watch movement, introduced in 1972, initially featured a separate click and click-spring in its early sample models which were later replaced by a single-part click design. This manual wind movement includes a sweep second function and a 24-hour hand. It has been used continuously since 1972.
The A Michel 396 features the following functions:
- 24h hand
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.105 x 300 x 9.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
