A Michel 396
Ligne: 5.75 x 8.5'''
Jewels: 15/17
Power Reserve: 42 hrs
Frequency: 18000 vph
Type: Manual Wind
Size: 12.8 x 19.6 mm
Height: 3.55 mm
Hands: 1.05 x 0.45 mm
Base: Aurore 10
The A Michel 396 watch movement features either round or straight corners. It offers an optional bimetallic screw balance. There is no available information regarding the differences between the Aurore 10 and A Michel 396 movements. The A Michel 396 movement is a manual wind watch movement.
The A Michel 396 features the following functions:
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 312 | Ordinary/None | Buy staff |
| 2082 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.085 x 240 x 7.0 mm | GR3089 | Manual | Buy mainspring |
| 1.20 x 0.080 x 250 x 7.5 mm | Manual | Buy mainspring | |
| 1.20 x 0.080 x 240 x 7.0 mm | GR2870 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
