A Michel 394
Ligne: 18'''
Jewels: 6
Power Reserve: 38 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1910
Diameter: 41.05 mm
Height: 7.0 mm
Hands: 1.85 x 0.55 mm
Base: Langendorf 21
The A Michel 394 watch movement features a cylinder escapement and an alarm wheel with a setting hand beared in dial. The alarm setting is only counterclockwise. It includes a ratchet on the dial side, and a crown mechanism with a single-arm rocker bar. This movement has stem wind and pin set alarm functionality. It is equipped with an adjustable stud holder and incorporates Incabloc shock protection. The A Michel 394 movement was commonly used in watches around the year 1910.
The A Michel 394 features the following functions:
- Adjustable Stud Holder
- Incabloc Shock Protection
- Stem wind and pin set alarm
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 5023 | Ordinary/None | Buy staff |
| 5187 | Ordinary/None | Buy staff |
| 5187 | Incabloc | Buy staff |
| 5023 | Shockproof | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.070 x 200 x 6.0 mm | GR3185 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
